3181A-S

Single-band 1X1 802.11b/g/n WIFI Module Wireless Module SDIO WiFi Module 2.4GHz Module
没有此类产品
Page view:
Product description

Features

Operate at ISM frequency bands (2.4GHz)


Maximum rate of 72.2 Mbit/s@HT20 MCS7
SDIO interface for Wi-Fi

High transmitting power

High receiving sensitivity

PHY supporting IEEE 802.11b/g/n

MAC supporting IEEE802.11 d/e/h/i/k/v/w

WFA WPA, WFA WPA2 personal, and WPS2.0 for Wi-Fi

Applications

IPC、Video Doorbell、Drone and other electronics

Block Diagram

Parameters

Model No 3181A-S Main Chipset Hi3881
Interface SDIO WiFi Standard IEEE802.11 b/g/n
Data Rate 72.2Mbps Certification RoHS,REACH
RF Antenna External Antenna OS Supported LiteOS/Linux
Operating Frequency 2.4G:2.400~2.4835GHz Operating Voltage 3.3V
Dimension L12.0mm * W12.0mm * T2.3mm RF Chain 1T1R
Operating Temperature -40°C to 85°C Storage Temperature -40°C to 85 °C

Dimensions




Key Words: Wireless Module SDIO WiFi Module 2.4GHz Module
Corresponding parameter set not found, please add it in property template of background
暂未实现,敬请期待
暂未实现,敬请期待

Download

Please download the specification from Download Center
