6222D-UUB-01

Wi-Fi Dual-band 2X2 11ac +Bluetooth 4.2 Module Bluetooth WiFi Module WiFi Module 5GHz USB WiFi Module

Product classification:

RF 2.4G/5.8G Wi-Fi/BT Module

Key words:

6222D-UUB-01

wifi module 5ghz

bluetooth module

usb wifi module

long range wifi module

undefined
undefined
undefined
  • undefined
  • undefined
  • undefined
consultation

Features

Highly integrated wireless local area network(WLAN) system-on-chip (SOC) for 5 GHZ 802.11ac, or 2.4G/5G 802.11n WLAN applications.

Dual-stream spatial multiplexing up to 867 Mbps data rate

Supports 20/40MHz at 2.4GHz and supports 20/40/80MHz at 5GHz

Supports USB interface for WLAN and Bluetooth.

Supports Bluetooth V4.2+HS, BLE and be backwards compatible with Bluetooth 1.2, 2.X+ enhance data rate.

Supports Bluetooth for class1 and class2 power level transmissions.

Applications

OTT/IPTV/DVB/STB、Tablet PC、Laptop、Smart TV、IPC/NCR、Industrial Controllers 、DVR、Doorbell、Projector、AR/VR、Printer/POS Terminal、Electronic Scale、Drone、Robot、HDMI Transmitter、Smart Gateway、Education、Toys and other Consumer Electronics

Block Diagram

Parameters

Model No 6222D-UUB-01 Main Chipset RTL8822BU
Interface USB Wifi Standard IEEE 802.11 a/b/g/n/ac+BLE4.2
Data Rate 867Mbps Certification RoHS,REACH
RF Antenna External Antenna OS Supported Linux/Android/Windows
Operating Frequency 2.4G:2.400GHz~2.497GHz(2.4G ISM Band)
5.8G:4.900GHz~5.845GHz(5.0G ISM Band)
Operating Voltage 3.3V
Dimension L27.0 * W18.0 * T1.9 mm RF Chain 2T2R
Operating Temperature 0°C to 70°C Storage Temperature -40°C to 85°C

Demensions




Key Words: Bluetooth WiFi Module
WiFi Module 5GHz USB WiFi Module




Download

Please download the specification from

Download Center
